Starblaze TIG Wire ER630L

STARBLAZE TIG 630 is a premium, precipitation-hardening stainless steel TIG welding rod formulated to join high-strength alloys like 17-4 PH steel.
Complying strictly with the international AWS A5.9 ER630 specification, this solid wire deposits a martensitic chemistry modified with niobium.
This metallurgical configuration allows the weld deposit to mirror the mechanical properties of the base metal, responding directly to post-weld precipitation hardening (age hardening) treatments to achieve immense structural strength and wear resistance.

Product Overview & Composition
Alloy Classification: Formulated to meet international certifications
AWS/SFA A5.9: ER630 and EN ISO 14343-A: W 17 4 PH.

Chemical Profile: Enriched with a specialized composition of 16.0% to 16.75% Chromium (Cr), 4.5% Nickel (Ni), and 3.25% Copper (Cu).
Niobium Stabilization: Modified with a controlled fraction of Niobium (Nb) or Columbium (Cb) to facilitate sub-microscopic precipitate formations during aging cycles.
Mechanical Capability: Capable of generating up to three times the yield and tensile strength of conventional austenitic grades (like 304 or 316) following appropriate heat treat scheduling.

Compatible Base Materials
This filler metal is tailored to provide a direct physical, chemical, and heat-treatment match for:
17-4 PH (UNS S17400) type precipitation-hardening alloys.
15-5 PH (UNS S15500) structural steels.
High-load components demanding premium edge surfacing overlays on unalloyed steel substrates.

AWS A5.9 ER630
EN ISO 14343-B G/W 630
